1x7/ 7x7/ 1x19/ 7x19PVC+Galvanized Steel/ Stainless Steel/copper Plated Steel

Galvanized Plastic Coated Steel Wire Rope 10mm 12mm 1x7 7x7 1x19 7x19

Key Specifications

Product Name	Plastic Coated Steel Wire Rope
Material	PVC+Galvanized Steel/ Stainless Steel/copper Plated Steel
Color	Transparent/blue/yellow/violet/black
Diameter	1-12mm
Structure	1x7/ 7x7/ 1x19/ 7x19
Package	Wooden Reel/ Iron Reel/ Plastic Reel/ Roll

Brand Name

CSW

Model Number

CSW-PC-Color

Place of Origin

Shandong, China

Certification

SGS,CE,ISO,ROHS

Standard Packaging

500-3000m/ Reel

Delivery Time

5-10 Days

Payment Terms

T/T

Supply Ability

70000 Tons/ Year

Need this exact spec?Factory quote within 24 hours — send diameter, quantity & destination port.

Inquire Now WhatsApp

Double Protection Structure: Internal steel wire rope provides strong tensile strength while external PVC layer isolates corrosive elements including moisture, acidity, and dust, significantly extending service life Multi-Scenario Adaptability: Suitable for applications ranging from household drying facilities to industrial lifting equipment, and from outdoor garden construction to marine environment operations Low Maintenance Cost: Smooth surface minimizes dust accumulation, eliminating frequent rust removal or oiling requirements with simple daily cleaning Enhanced Safety Performance: PVC layer effectively reduces rebound risk after wire rope breakage while preventing scratches and hazards from direct metal contact

s Product Certification Our steel wire rope meets international production standards and holds multiple certifications including SGS, CE, and ISO.

Size	Wire Rope Dia	After Coated Dia	Reasonable Loading	100m Weight	Rope Structure
1mm	0.8mm	1mm	11.5kg	0.33kg	7*7
1.2mm	1mm	1.2mm	15.9kg	0.49kg	7*7
1.5mm	1.2mm	1.5mm	30kg	0.72kg	7*7
2mm	1.5mm	2mm	41.8kg	1.17kg	7*7
2.5mm	1.5mm	2.5mm	52kg	1.99kg	7*7
3mm	2mm	3mm	73.5kg	2.53kg	7*7
4mm	3mm	4mm	159.3kg	4.96kg	7*7
5mm	4mm	5mm	237.8kg	8.2kg	7*7
6mm	5mm	6mm	367.5kg	12kg	7*19
8mm	6mm	8mm	516.2kg	17.9kg	7*19
10mm	8mm	10mm	856.5kg	29.5kg	7*19
12mm	10mm	12mm	1400kg	45.8kg	7*19

Inner Wire Dia (mm)	Outer Dia (mm)	Application	Min Breaking Load (KN)
1	1.8-2.0	Curtain rails, small hanging accessories	0.8-1.0
2	3.0-3.5	Household drying racks, small swings	2.5-3.0
3	4.5-5.0	Sunshade, garden towing rope	5.0-6.0
5	7.0-8.0	Industrial cranes, ship cables	12-15
8	10-12	Large lifting equipment, bridge guardrails	30-35
